SEE

SEE
  • Light gray
  • Colored or clear lid
  • Protection:  NEMA 4x, IEC529, IP65, UL-508-4X
  • Indoor version
  • Indoor: UL94 5VB, clear lids UL95 5VA
  • Temp resistance: -40oC to +70oC
SEE

Data Sheet

MATERIAL:
Indoor ABS/PC blend
Clear lid

Polycarbonate



DIMENSIONS: MM IN
SOLID LID CLEAR LID W L H W L H
INDOOR VERSION
SEE10543 SEE10563 190 290 140 7.48 11.42 5.51 Drawing
SEE10547 SEE10567 290 390 160 11.42 15.35 6.30 Drawing
SEE10553 SEE10573 350 465 200 13.78 18.31 7.87 Drawing

OPTIONS: Machining and printing Data sheet
